Fuel Injector Tester & Cleaning Tool Kit — 8 Pulse Modes — Automotive Injector Diagnostic Tool

Fuel Injector Tester & Cleaning Tool Kit - 8 Pulse Modes - Automotive Injector Diagnostic Tool
MP72960 SUNDOH

【Test 2 Injectors Simultaneously】 This fuel injector cleaner and tester helps you diagnose and clean injectors, making it easy to identify common faults such as sticking, clogging, leaking, or burnout conditions. Unlike other fuel injector testers that feature only a single pulse output channel (one pair of black and red test leads), our device features two pulse output channels (two pairs of test leads), allowing you to test two fuel injectors simultaneously for direct comparison.
【8 Pulse Modes, Mode Lock Function, and LCD Display】 The fuel injector tester kit features an LCD display and is designed with 8 distinct pulse modes. These consist of 4 pulse signal output modes and 2 output voltage levels: Short / Medium / Long / Continuous pulse modes, combined with High / Low (12V / 5V) power drive modes. This fuel injector cleaner allows you to distinguish between good and faulty injectors while the engine is turned off. You can select any mode as needed, and the "Mode Lock" function ensures consistent testing conditions throughout the process.
【4 Adapter Sizes and Wide Compatibility】 Our injector cleaner is compatible with 12V fuel injectors across almost all vehicle models, supporting both EFI and GDI systems. It comes with one large and one small universal adapter suitable for most injector models (with the exception of Audi and BMW). To further expand its compatibility, we have added two additional adapters: a medium-sized adapter suitable for Audi, Volkswagen, and similar vehicles; and a specialized adapter featuring a threaded port designed specifically for BMW N-series engines (e.g., N14, N18, N20, N26, N53, N54, N55, N63, S63).
【40-Inch Power Cord and 20-Inch Test Leads】 The power cord extends up to 40 inches (100 cm), while the test leads measure 20 inches, ensuring easy connectivity and convenient operation. The wiring is constructed from high-quality silicone material, offering superior resistance to both high and low temperatures. The fuel injector cleaning kit is powered by a 12V battery or an external 12V DC power adapter (a minimum current of 1.5A is recommended). It operates with the engine turned off and can be used in conjunction with any fuel pressure tester (Note: Suitable for gasoline vehicles only; not applicable to diesel engines).
【Reverse Polarity and Short-Circuit Protection】This fuel injector cleaner and tester features built-in protection against reverse power input polarity and output short circuits. If the fuel injector is damaged or the pulse output terminal experiences a short circuit, the power indicator light on the cleaning tool will flash to alert you.
